Shelly LAN Switch
42.00 JOD
Available
LAN DIN-mountable switch
Shelly LAN Switch is a DIN-mountable Ethernet switch with 5 RJ45 ports. It offers a seamless solution to expand your network capabilities without the hassle of extensive rewiring. Engineered for reliability and performance, it ensures a consistent and stable direct network connection to your devices, providing you with peace of mind and confidence in your network infrastructure.
- DIN-mountable
- 5 RJ45 ports
- 10/100mbps
- LED indicators
- 110V – 230V power supply; No need for additional adapters
specifications
| Size (HxWxD): | 96x53x59 mm / 3.78×2.01×2.32 in |
|---|---|
| Weight: | 87 g / 3 oz |
| Screw terminals max torque: | 0.4 Nm / 3.5 lbin |
| Conductor cross section: | 0.5 to 2.5 mm² / 20 to 14 AWG |
| Conductor stripped length: | 6 to 7 mm / 0.24 to 0.28 in |
| Mounting: | DIN-rail |
| Shell material: | Plastic |
| Shell color: | Black |
| Ambient working temperature: | -20°C to 40°C / -5°F to 105°F |
| Humidity: | 30% to 70% RH |
| Max. altitude: | 2000 m / 6562 ft |
| Power supply: | 110 – 240 VAC |
| Power consumption: | < 1 W |
| External protection: | Tripping characteristic B or C,max. 16 A max. rated current,min. 6 kA interrupting rating,energy limiting class 3 |
