Shelly Qubino Wave Shutter

34.00 JOD

Years Manufacturer Warranty

Available

Z-Wave™ shutter control with power measurement, 10 A per channel

Automate and remotely control the position of roller shutters, blinds, windows, awnings, pool covers, and other devices powered by bi-directional AC motors.

Control the tilt position (angle) of the venetian blind slats
Supports push-buttons/momentary switches, and toggle switches
Power metering
Extremely low power consumption: < 0.3 W
Z-Wave frequency band: 868.4 MHz (CEPT countries)
Latest technology: Z-Wave 800 Series
Automatic set-up with SmartStart
Security 2 Authenticated for the highest level of security
Over-the-air firmware updates
Works with Z-Wave-certified gateways and over 4,000 Z-Wave devices

*A gateway (smart hub) is not included. A gateway (smart hub) is required for the configuration of the device.

specifications

Size (H x W x D):	37 mm x 42 mm x 16 mm ± 0.5 mm / 1.46 in x 1.65 in x 0.63 in ± 0.02 in
Weight	29 g / 1.02 oz.
Mounting	Wall console
Screw terminals max. torque	0.4 Nm / 3.5 lbin
Conductor cross section	0.5 to 1.5 mm² / 20 to 16 AWG
Conductor stripped length	5 to 6 mm / 0.20 to 0.24 in
Shell material	Plastic
Color	Black
Ambient temperature	-20°C to 40°C / -5°F to 105°F
Humidity	30% to 70% RH
Max. altitude	2000 m / 6562 ft.
Power supply	110–240 V AC ±10%
Power Consumption	< 0.3 W
Power measurement	Yes
Max. switching voltage AC	240 V
Max. switching current AC	10 A per channel
Z-Wave frequencies band(s)	868,4 MHz; 865,2 MHz; 869,0 MHz; 921,4 MHz; 908,4 MHz; 916 MHz; 919,8 MHz; 922,5 MHz; 919,7-921,7-923,7 MHz; 868,1 MHz; 920,9 MHz
Z-Wave repeater	Yes
Z-Wave range	Up to 40 m indoors (131 ft.) (depends on local condition)
Maximum radio frequency power transmitted in frequency band(s)	< 25 mW
CPU	Z-Wave S800
Overcurrent protection	Yes
Overheating protection	Yes
