Shelly Uni
Available
Smart Wi-Fi-operated module
With this tiny insulated chip, you can control sensors and measure data to trigger actions.
- Suitable for low-voltage AC and DC applications (12V – 24V AC and 12V-36V DC)
- Easy control through the Shelly app, as well as various protocols, platforms, and voice assistants.
- Has an embedded web server and connects to your Wi-Fi network
specifications
| POWER | |
|---|---|
| Power supply AC | 12V – 24V |
| Power supply DC | 12V – 36V |
| SPECIAL FUNCTIONS | |
| Inputs | 2 Separated digital inputs from 2.2-36V DC and 12-24V AC |
| Outputs | 2 Potential free outputs up to 24VAC and 36VDC, max 100 mA, 300mW each |
| Overload protection | No |
| Power measurement | 1 ADC – dual ranges from 0-12V and 0-30V |
| FEATURES | |
| Channels | 2 Channels |
| Operational temperature | 0 to + 40 °C |
| Device power consumption | < 1 W |
| Intelligent On/Off | Yes |
| Sunrise/Sunset | Yes |
| Weekly Schedule | Yes |
| UL Listed option | No |
| CONNECTIVITY | |
| Wireless/WiFi Protocol | 802.11 b/g/n |
| Radiofrequency | 2400 – 2500 MHz |
| Range | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
| DIMENSIONS | |
| Size | 20mm x 33mm x 13mm |
